    Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015

    Ask Lasest Price
    Brand Name : WNK
    Model Number : WNK80MA
    Price : $15.00/Pieces
    • Product Details
    • Company Profile

    Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015

    Low Cost Digital Mini Water Air Pressure Transmitter SPI/IIC I2C Output


    WNK80MA Gauge/Absolute/Sealing Pressure Transmitter
    Applicable media
    Liquid, Gas
    Pressure range
    0~60bar
    Pressure measurment
    Gauge Pressure, Sealing pressure
    Output
    4-20mA/0.5-4.5V/1 -5V/0-10V/I2C
    Accuracy(linearity,Hysteresis and Repeatability)
    0.5%F.S.(Typical)
    Power supply
    24VDC/12VDC/5VDC/3.3V
    Compensation temperature
    -20~85ºC
    Ambient temperature
    -40~125ºC
    Working temperature
    -40~125ºC
    Temperature drift(zero)
    ±0.15% F.S. (-20~85ºC)
    Temperature drift(full range)
    ±0.15% F.S. (-20~85ºC)
    power(electrical) connect
    Parkard, M12, DIN43650, Cable outlet
    Mechanical connection
    G1/4, 1/4NPT, 1/8NPT, M12*1.5, customize
    Housing material
    304 stainless steel(inner core is 316 stainless steel)
    Protection
    IP65

    >>> Applications
    - Automobile, Compressor and Refrigeration Industry
    - Engineering machinery
    - Pressure control and monitor
    - Water treatment system
    - Hydraulic and Pneumatics
    - HAVC and BAS Control
    - Pump, fitness equipment, household appliances
    - Factory Automation
    - Fluid Control and Instrumentation Systems


    Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015

    Product Show

    Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015


    ,Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015

    Company Information

    Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015

    Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015


    Exhibition

    Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015


    Certification

    Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015


    Packaging & Shipping

    Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015

    Water Air Mini Pressure Transmitter SPI IIC I2C Output ISO9001 2015

    FAQ

    Q: Are you trading company or manufacturer ?

    A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.

    Q: What's your quality control system?

    A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

    Q: What is the warranty of your products?

    A: 12 month from shipment date, for non-man-made damages.

    Q: Shipping and Delivery

    A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

    Large orders are recommended to ship by sea
