IP68 Water Level Transmitter 24V DC Polyvinyl Fluoride Cable

Ask Lasest Price
Brand Name :	WNK
Model Number :	WNK8010
Supply Ability :	100 Set/Sets per Week Level measuring instruments/4-20mA Liquid sensor/ Liquid level t
Price :	$35.00 - $50.00/Sets
Payment Terms :	T/T, Western Union, MoneyGram, Paypal
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

IP68 Water Level Transmitter 24V DC Polyvinyl Fluoride Cable

High Accuracy IP68 4-20mA Submersible Level Transmitter Water Level Sensor

Specifications

Output signals
Output	4-20mA, 0-10mA, 0-5V, 1-5V,Customization
Measured range
Measured range	0-0.5~200mH₂O
Max overload	150% of sensor range
Parameters
Applicable media	Liquid, Water
Accuracy	±0.2% FS/year, ±0.5% FS/year
Stability	±0.25% FS/year
Housing material	Stainless steel
Cable material	Polyvinyl Fluoride, PTFE
Power supply	24V DC
Ambient temperature	-20~85℃
Process temperature	-20~85℃
Compensation temperature	-20~85℃
Protection class	IP68

IP68 Water Level Transmitter 24V DC Polyvinyl Fluoride Cable

1. Our WNK8010 liquid leve sensor with high performance diffused silicon piezoresistive pressure sensor as the measuring element.

2. With the reliable amplified circuit and precision temperature compensation,to transfer the gauge or absolute pressure of measurement medium to standard voltage or current signal.

3. This product comes with compact profile, easy to install,it can measure the level height directly when through into the liquor.

Product Dimension & Installation

IP68 Water Level Transmitter 24V DC Polyvinyl Fluoride Cable

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea
