4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size

Ask Lasest Price
Brand Name :	WNK
Model Number :	WNK8010-TT
Supply Ability :	200 Set/Sets per Day Water level transmitter
Price :	$35.00 - $50.00/Sets
Payment Terms :	T/T, Western Union, MoneyGram, Paypal
Delivery Time :	5-8 work days
MOQ :	1 sets

Add to Cart

Product Details
Company Profile

4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size

4-20mA 0.5-4.5V Analog Level Sensor Transmitter For Water Liquid

Packaging & Shipping

WNK8010

Adopting diffusion silicon oil-filled sensor

High Stability

Intergral small size

For tank, pool, underwater etc open vessel measurement

Product Name	4-20mA 0.5-4.5V Analog Level Sensor Transmitter For Water Liquid
Pressure measurment	Liquid,Water
Accuracy	±0.25% FS/year, ±0.5% FS/year
Output	4-20mA, 1-5V, 0.5-4.5, 0-5V, 0-10V, IIC,HART,RS485
Power supply	24V/12V/5V/3.3V
Ambient/Process/Compensation temperature	-20~80℃
Housing material	Stainless steel
Ingress Protection	IP68

4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size

- Our WNK8010 liquid leve sensor with high performance diffused silicon piezoresistive pressure sensor as the measuring element,

- With the reliable amplified circuit and precision temperature compensation, to transfer the gauge or absolute pressure of measurement medium to standard voltage or current signal.

- This product comes with compact profile, easy to install, it can measure the level height directly when through into the liquor.

Applications

• Water tank level measurement and control.

• Fuel tank level measurement and monitor (diesel, gasoline, kerosene and so on).

• Liquid level measuring in tank, rivers, lake, sea, well, tube, underground water and so on.

• Special occasion such as high temperature liquid (up to 100 degree C), strongly corrosion liquid level measurement (request by customized.)

Features

• Adopting diffusion silicon oil-filled sensor

• Max measure range up to 200 meters or more

• High Stability, provide 0.1, 0.2, 0.5 accuracy for option

• Factory direct price

4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size

Specifications

4-20mA 0.5-4.5V Analog Water Level Sensor High Stability Intergral Small Size

Low cost Water Level Sensor for Deep Well, Open Tank, Pool

Ordering Code

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea
